OllyDbg 2.01h


Teddy Rogers

2 Screenshots

About This File

OllyDbg is a 32-bit assembler level analysing debugger for Microsoft® Windows®. Emphasis on binary code analysis makes it particularly useful in cases where source is unavailable. OllyDbg is a shareware, but you can download and use it for free. Special highlights are:

  • Intuitive user interface, no cryptical commands
  • Code analysis - traces registers, recognizes procedures, loops, API calls, switches, tables, constants and strings
  • Directly loads and debugs DLLs
  • Object file scanning - locates routines from object files and libraries
  • Allows for user-defined labels, comments and function descriptions
  • Understands debugging information in Borland® format
  • Saves patches between sessions, writes them back to executable file and updates fixups
  • Open architecture - many third-party plugins are available
  • No installation - no trash in registry or system directories
  • Debugs multithread applications
  • Attaches to running programs
  • Configurable disassembler, supports both MASM and IDEAL formats
  • MMX, 3DNow! and SSE data types and instructions, including Athlon extensions
  • Full UNICODE support
  • Dynamically recognizes ASCII and UNICODE strings - also in Delphi format!
  • Recognizes complex code constructs, like call to jump to procedure
  • Decodes calls to more than 1900 standard API and 400 C functions
  • Gives context-sensitive help on API functions from external help file
  • Sets conditional, logging, memory and hardware breakpoints
  • Traces program execution, logs arguments of known functions
  • Shows fixups
  • Dynamically traces stack frames
  • Searches for imprecise commands and masked binary sequences
  • Searches whole allocated memory
  • Finds references to constant or address range
  • Examines and modifies memory, sets breakpoints and pauses program on-the-fly
  • Assembles commands into the shortest binary form
  • Starts from the floppy disk

and much, much more!


What's New in Version 2.01h   See changelog

Released

New version with many new features, among them:

  • Help on 77 pages. Please read it first - most of new features are described there
  • Multilanguage GUI (experimental, as yet no translation files - please do it by yourself)
  • Support for AVS instuctions (as yet no AVS2 and high 16 bytes of YMM registers are not displayed)
  • Call stack window (similar to the version 1.10)
  • Handles window (similar to the version 1.10)
  • SEH and VEH chains. To decode addresses of VEH handlers, OllyDbg hacks NTDLL.RtlAddVectoredExceptionHandler(), therefore process must be started from the OllyDbg
  • Multibyte character dumps
  • .udl image libraries, replace scan of object files from v1.10
  • Search for integers and floats in dump
  • Search for procedures (entry points)
  • Limited support for NTFS streams
  • Drive dump
  • Software breakpoints that use INT1, HLT, CLI, STI or INSB instead of INT3
  • Multiple watches in one line, support for repeat count
  • Dump of arrays of structures
  • Micro-analysers
  • Accelerated search
  • Assembling of immediate data statements (DB xx etc.)
  • Highlighting in run trace
  • Up to 2 ordinals per address
  • Limited support for Win95 via Microsoft Layer for UNICODE
  • More tricky code sequences
  • Show free memory, or was it the previous version?
  • Multiple bugfixes

Yes, you understand it correctly. OllyDbg graphic interface supports multiple languages. All you need is the corresponding language file. Currently there are none, but I expect that the volunteers will be able to make more or less complete translations.

Plugins compiled for OllyDbg 2.01 beta are 100% compatible with v2.01. PDK will be updated... soon...

Preliminary version of Disassembler 2.01 is almost ready. That is, the sources are more or less final but documentation and ready-to-use DLLs are still missing. I release Disasm 2.01 under GPL v3. Commercial licenses are also possible.
