[UnpackMe] Simple UnpackMe

[SHADOW_UA]

Packer: Modified UPX

UnpackME_PC-RET.zip

Edited June 13, 2014 by SHADOW785

[njkermk]

unpacked

UnpackME_dump.7z

Edited June 14, 2014 by njkermk

[njkermk]

del

Edited June 14, 2014 by njkermk

[kakamail]

After unpacking exception raise at 0x44D739, i fixed exception1 by changing [00471800]->0. And then i meet another exception, don't know how to bypass this one

[njkermk]

kakamail

a little help to you

Edited June 14, 2014 by njkermk

[DMichael]

kakamail

a little help to you


what is the software in the screenshot?

[LCF-AT]

Hi,



there are only 2 calls to extra UPX code and one little routine where the real bytes get written into after access the second call.So this little xoring dosen't match in the dumped file = created no real code at VA 0044D734 = still non code to execute = access violations.Just fix both calls to UPX (see inside what it calls) and fix stolen code routine = unpacked and no violations anymore.Optional you can also patch the TLS (0040603D) check which I always do in delphi.

<00406075>

call 00405854

<00403F4E>

call 00403DF8

<0044D734>

	PUSH EBX

	ADD ESP,-0x1C

	MOV EBX,EAX

	MOV EDX,ESP

	MOV EAX,EBX

	CALL 0044D69C

	TEST AL,AL

	JNZ SHORT @L00000001

	MOV EDX,ESP

	MOV EAX,EBX

	CALL 0044E0C4
@L00000001:

	ADD ESP,0x1C

	POP EBX

	RETN

	nop   ; I added nop because command below has 3 bytes in original

	LEA EAX,DWORD PTR DS:[EAX] ; just a little MultiASM bug

	PUSH EBP

	MOV EBP,ESP

	PUSH EBX

	MOV EBX,EAX

	CMP BYTE PTR DS:[EBX+0xA4],0x0

	JNZ SHORT @L00000002

	MOV EAX,DWORD PTR DS:[EBX+0x30]

	TEST EAX,EAX

	JE SHORT @L00000003

	LEA EDX,DWORD PTR SS:[EBP+0x8]

	PUSH EDX

	PUSH 0x0

	PUSH 0xB020

	PUSH EAX

	CALL 004069D4

	JMP SHORT @L00000003
@L00000002:

	MOV EAX,DWORD PTR DS:[EBX+0xA8]

	CALL 00413BF4

	MOV EAX,0x8

	CALL 00402A28

	MOV EDX,DWORD PTR SS:[EBP+0x8]

	MOV DWORD PTR DS:[EAX],EDX

	MOV EDX,DWORD PTR SS:[EBP+0xC]

	MOV DWORD PTR DS:[EAX+0x4],EDX

	MOV EDX,EAX

	MOV EAX,DWORD PTR DS:[EBX+0xA8]

	CALL 00413AB4
@L00000003:

	POP EBX

	POP EBP

	RETN 0x8

greetz

UnpackME_Unpacked.rar

[kakamail]

@njkermk: hi, it seems you used notepad++ to compare 2 files. Can you tell me the way you found that area? As i did, i set bp on memory and then i saw Xor function.@LCF-AT: Hi, is there any way to recognize these 2 calls? (Yes, experience is one way)

[LCF-AT]

Hi again,



1.) Unpack the file normaly = OEP / Dump / Fix

2.) Test dump = access violations

3.) Check AV address

Address=0044D739 Message=Access violation when reading [68BF1DD4]
KiUser API you can hook too.

0012FC8C   0012FC94

0012FC90   0012FCB0

0012FC94   C0000005  <-- Violation

0012FC98   00000000

0012FC9C   00000000

0012FCA0   0044D739  0044D739 <--- address of Vio

4.) Check the Violation code address

0044D733  RETN

0044D734  ADC EAX,0xCDE4C481

0044D739  FIMUL DWORD PTR DS:[EBX+0xE8C1CDD4]  <-- Vio here

0044D73F  POP ECX

So you see above is a ret command = end of routine above and at ....34 start some strange code till some bytes below there you can see again normal code.Now the first command does not call a exception at ...34 its just a ADC command so now just check the top of ....34 VA whether this get access too if you set a HWBP on it or analyse the file + search for references =

References to 0044D734

Address    Disassembly

0044A5A9   CALL 0044D734

0044D96E   CALL 0044D734

we found 2 call commands who access this VA directly.So now we know that the first address get access is 0044D734 and there should also start the real code.Now just set a HWBP access on 0044D734 in dump and run.

0047114E  MOV EAX,DWORD PTR DS:[ECX]  <-- here the access

00471150  JMP SHORT 00471155   <--- you stop here
EAX E4C48270 <--- DWORD inside of [VA]

ECX 0044D734 <--- Our VA

EDX 00000010

EBX 0044F0CC

ESP 0012FF80

EBP 0012FFC0

ESI FFFFFFFF

EDI 7C920228 ntdll.7C920228

EIP 00471150

In the stack you can see from where it was called from some bytes below = you got one call now.



Now if you check this one call at...

00403F4E  CALL 00471135

....then check what inside happens....

004711F2    MOV EDX,0x10                    ; set counter

004711AA    MOV ECX,0x44D734                ; stolen code VA

0047114E    MOV EAX,DWORD PTR DS:[ECX]      ; [VA] to eax

004711CC    XOR EAX,DWORD PTR DS:[0x471800] ; xor value with 123

0047115C    MOV DWORD PTR DS:[ECX],EAX      ; mov new dword back to [VA]

004711DC    ADD ECX,0x4                     ; add 4 bytes to VA

00471225    DEC EDX                         ; sub one byte to counter

0047113F    JNZ SHORT 0047114E              ; Dosen't jump if edx 0 = loop end

....so you see there happen a xoring at VA 44D734 with a value which is stored at [0x471800] and the new bytes get copied to code = results of xoring = original DWORD get xored with value X = new DWORD = copied to code at same VA.The counter has a lenght of 10 = 10 x 4 bytes = 40 bytes to xor startet from VA 44D734 till 44D734 + 40 bytes = lenght of code which get changed.



So the main thing is here which value you have inside of VA [0x471800] = xoring value.If you check this in original file then you will see...

00471800  00000123

....and in my dump I have a value of...

00471800  00000365

...so you see it differs.Now check where it does copy the value 365 in your dumped file...set HWBP access on this VA and run...

004710BD  MOV DWORD PTR DS:[0x471800],EBX <--- ebx = 365

004710C3  JMP SHORT 004710C6  <-- you stop
Stack +20 = call from
00406075  CALL 00471000 <-- second call you need to check

.....

00471129  MOV EAX,0x400080

00471108  MOV EDX,0x3D0

00471069  XOR EBX,EBX

00471038  CMP BYTE PTR SS:[EAX],0x0  ; check for 00 byte / loop top

004710F5  JNZ SHORT 004710DA         ; jump if not 00 byte inside [VA]

-----------------

004710F7  NOP                        ; <-- set BP here = 00 byte in [VA]

-----------------

004710DA  INC EAX                    ; inc VA

004710CB  DEC EDX

0047101B  JNZ SHORT 00471038         ; jumps if edx not 00 and jumps back to loop top

-----------------

0047101D  JMP SHORT 00471020         ; <-- set BP here edx = 00

-----------------
Now you stop at 004710F7 VA eax = VA 00400082 which holds a 00 byte inside.
004710F7  NOP

0047102A  INC EBX

004710DA  INC EAX

004710CB  DEC EDX

0047101B  JNZ SHORT 00471038  <--- same VA as above

0047101D  JMP SHORT 00471020  <--- so we need to stop here = edx 00
Remove BP at 004710F7 and keep 2. BP on at VA 0047101D
EAX 00400450 <--- VA we got after this loop

ECX 0012FFB0

EDX 00000000 <--- edx 0 loop end

EBX 00000365 <--- ebx 365

ESP 0012FF80

EBP 0012FFC0

ESI FFFFFFFF

EDI 7C920228 ntdll.7C920228

EIP 0047101D
004710BC  MOV DWORD PTR SS:[0x471800],EBX <-- 365 to xor location VA holder
00471049  RDTSC

00471090  MOV ECX,DWORD PTR SS:[ESP]

0047100A  SUB ECX,0x826  = 00405854 after in ecx

00471080  LEA EAX,DWORD PTR DS:[ECX+0x4A850]  = 004500A4 in eax

004710AE  CALL ECX = call 00405854 = missing original call
back and return to code....
Now if you check the same with the original file then you get this...
0047101D  JMP SHORT 00471020    <-- here you stop
EAX 00400450  <--- VA we got after this loop

ECX 24575965

EDX 00000000

EBX 00000123  <-- Other value

ESP 0012FF80

EBP 0012FFC0

ESI 00000000

EDI 30000007

EIP 0047101D

...if you now check the VA you got in eax at the end = 00400450 then you see it does belong to your PE Header and in the original file you can see a lot trash code inside of this address which you not have in your dumped file and that the different.



Solutions can be:

------------------------------

Fix missing 2 calls + restore original code / 40 bytes as I did in my dumped file.

or

Just change...

004711CC  XOR EAX,DWORD PTR DS:[0x471800]

to

004711CC  XOR EAX,0x123

004711D1  NOP

or

Just copy original PE Header into your dumped file at any patch location you want.



All three ways are possible and simplest fix is the xor eax,123 patch.



So I hope this little short tutorial is helpfully for you now.



greetz





[njkermk]

what is the software in the screenshot?

Notepad++ Compare plugin



@njkermk: hi, it seems you used notepad++ to compare 2 files. Can you tell me the way you found that area? As i did, i set bp on memory and then i saw Xor function.

@LCF-AT: Hi, is there any way to recognize these 2 calls? (Yes, experience is one way)



I simply compared the "Run trace" logs both programs using a compare plugin

Edited June 15, 2014 by njkermk

[kakamail]

@LCF-AT: Thank for your detailed tutorial, very useful.
@njkerm: hi, thank for that new useful command!
